BCDC 50A Rear Install Wiring Kit
More infoBCDC 50A Rear Install Wiring Kit
This rear of vehicle specific kit is designed to suit the installation of a 40 or 50amp BCDC DC to DC charger where the batteries are located at opposite ends of the vehicle.
Suitable for BCDC1240D and BCDC1250D, the BCDCWK-006 BCDC Wiring Kit has been designed to facilitate easy installation of a REDARC BCDC DC to DC Battery charger when the start battery and auxiliary battery are at the rear of the vehicle where the auxiliary battery is up to 8.5 m (28') away from the start battery.
This kit contains all the cables, fuses, fuse holders and connectors required to install the BCDC between the batteries. The cables are even pre-crimped on one end, and through use of the supplied terminal block, the other end of the cables can be trimmed to length to suit the specific installation. The Auxiliary Battery ground cable and solar to Anderson cable are sold separately.
FEATURES
- Suits rear of the vehicle installations
- Perfect for batteries at the rear of the vehicle.
- Complete wiring solution
- Cables supplied pre-crimped at one end
- All required cables, fuses, fuse holders and connectors included
KIT INCLUDES
- Brown, Black and Red Cable
- Terminal block with plastic cover
- M5 x 25mm Socket Head Screw
- M5 Nylon Locking Nuts
- M5 Flat Washer
- 150 mm (6") Red Cable (shorter)
- Fuse Kit
- Cable ties
- Wago® Connector and Boot
- Blue Cable
- 1m (39") Protective Conduit
The 4WD Shed is an Authorised Online Reseller for Redarc.
We also fit Redarc products in our mechanical workshop in Bayswater, Vic. Additional Costs May Apply
(BCDCWK-006)
| SKU | BCDCWK-006 |
| Barcode # | 9338628004348 |
| Brand | Redarc |
| Shipping Weight | 2.5000kg |
