Ultimate9 Nudge Bar Ford Ranger Raptor Next Gen 2022-On
More infoThe Ultimate Nudge Bar to suit Ford Ranger Raptor Next Gen (2022-On)
AUSSIE MADE & ADR COMPLIANT
Ultimate9 Nudge Bars provide a layer of protection for the front of your vehicle to shield vital components such as the radiator in the event of an accident.
Their design has a low impact on front-end weight and also functions as a mounting platform with provision for UHF & mobile phone antennas, sand flags and additional Ultimate9 LED Light Bars.
Designed, engineered and manufactured in Australia with Australian 3mm steel, the low-profile, over-bumper design offers minimal forward projection and is packaged with an Ultimate9 LED Light Bar nestled in the front face.
Finished in a Black textured powder coat with a Silver coated centre pan for corrosion protection and a modern feel.
Features:
- Australian-made: Designed, engineered, and manufactured in Australia.
- Steel Frame: 100% Australian-made steel.
- Airbag Compatible: Tested for airbag compatibility
- ADR Compliant: Designed to meet ADR standards.
- Low Profile: Over bumper design with minimal forward projection
- LED Lighting: Includes an Ultimate9 LED Light Bar 30"
- Lightweight: Weighing under 30Kg with included light bar
- Corrosion Protected: Zinc-plated.
- Finish: Black textured powder coat & silver coated centre pan
Ultimate9 Nudge Bars
Designed, Engineered, & Manufactured in Australia with Australian Steel.
Steel Construction
Manufactured with 100% Australian-made, 3mm steel for a rigid design.
Form-Fitting
Designed with modern vehicle styling in mind, contouring to the vehicle for minimal forward projection.
Integrated Light Bar
Bundled with an Ultimate9 LED Light Bar that nestles behind the front face with access holes for adjustment.
Coating
Zinc-plated for corrosion protection & powder coated with Dulux Mannex Black textured powder coat with a Silver Pearl coated centre pan.
Accessory Provision
Included points for UHF & mobile phone antennas, and additional Ultimate9 LED Light Bars.
ADR Compliant & Airbag Compatible
Designed to meet ADR standards and tested for airbag compatibility.
Ultimate9 Nudge Bars provide a layer of protection for the front of your vehicle to shield vital components such as the radiator in the event of an accident.
Their design has a low impact on front-end weight and also functions as a mounting platform with provision for UHF & mobile phone antennas, sand flags and additional Ultimate9 LED Light Bars.
Designed, engineered and manufactured in Australia with Australian 3mm steel, the low-profile, over-bumper design offers minimal forward projection and is packaged with an Ultimate9 LED Light Bar nestled in the front face.
Finished in a Dulux Mannex Black textured powder coat with a Satin Silver coated centre pan for corrosion protection and a modern feel.
Kit Includes:
- Nudge Bar
- Ultimate9 LED Light Bar 30"
- DTP Connector Kit
- Parking Sensor Extension Looms
- Parking Sensor Holders
- Parking Sensor Blanking Plates
- Slimline Number Plate Mount
- Installation Hardware
- Instructions
Specifications:
- Material (nudge bar): 3mm steel
- Material (centre pan): 1.6mm steel
- Material (mounts): 6mm steel
- Protective coat: Zinc Plated
- Finish Coat (nudge bar): Black textured Powder Coat
- Finish Coat (centre pan): Silver Powder Coat
- ADR Compliant
- Airbag Compatible
- Dimensions: (L) x (W) x (H)
- Weight: < 30Kg
Fitting is available at our Bayswater Vic workshop. Please call for a quote on 03 9720 8783.
The 4WD Shed is an Authorised Stockist & Installer of all Ultimate9 products.
Shipping Note: Flat Rate Shipping covers most metro areas in Australia. However extra freight charges may apply if residential or in a remote or regional area. We will contact you to advise if this applies to your order.
(ULTN05010)
| SKU | ULTN05010 |
| Brand | Ultimate9 |
| Shipping Weight | 31.0000kg |
